Novatel Wireless’ MiFi intelligent personal hotspot was one of our top 5 gadgets from ShowStoppers back in April, and had floored us a few months earlier in Barcelona. Having released their CDMA EVDO Rev.A MiFi 2200 on Verizon and Sprint to very


positive reaction, the company is now launching its GSM 3G HSPA model, the MiFi 2352. As well as the ability to share a single mobile broadband connection among up to five WiFi users, the MiFi 2352 brings a few new tricks to the table; check out the full SlashGear review after the cut.

MiFi 2352 unboxing slashgear 11 480x357

For the full rundown of what’s in the MiFi box, check out our video unboxing. Basically, in its SIM-free form as you see here, Novatel Wireless supply a global power-adapter with various plug inserts, a USB to microUSB cable, rechargeable 1,530mAh battery and a small printed Getting Started guide. The MiFi 2352 supports various connection speeds, from quadband (850/900/1800/1900MHz) GPRS/EDGE up to triband (900/1900/2100MHz) UMTS HSUPA/HSDPA. Network-depending, you can theoretically see up to 7.2Mbps downlink rates and up to 5.76Mbps uplink rates.

There’s no driver disc, because there needn’t be any drivers. As standard Novatel require no connection manager – the software Verizon supply with their CDMA MiFi is their own decision; Sprint’s version uses no such app – presuming you’re using the 2352’s WiFi connection. Setup is as speedy as dropping in your SIM, holding down the single button until the lights begin blinking, and then waiting for the MiFi to start spitting out a wireless connection. The default SSID is a sensible “MiFi_2352″ and by navigating to “http://www.mifi” you access the device’s locally-hosted homepage showing the number of connected clients (up to 5 are supported simultaneously), connection details and battery status.

Since sharing a capped HSPA data connection via an unsecured WiFi network seems a recipe for overage charges or disconnection, the first step for most users will be accessing the admin pages and setting up WEP, WPA or WPA2 encryption. Thankfully that’s straightforward with the MiFi’s basic but speedy UI; there are also options for MAC filtering and recording various logs of WiFi connections and modem events. The MiFi can be loaded with up to six “internet profiles”, each with corresponding settings to a different SIM; that way, if you regularly switch between carriers (say, if traveling) then it’s simple to flick between the presets.

As on a full-sized router, there’s also port filtering support, the ability to set custom permitted applications, port forwarding, a switchable DHCP server and VPN pass-through support. Unlike a normal router there’s also an optional power management setting which can shut the MiFi down after between 2 or 60 minutes of idle time. Once you’ve made all the tweaks you want, you can backup the settings to a connected computer.

MiFi 2352 HSPA indicator 480x230

Buttons may be in short supply on the MiFi, but blinking colored lights are not. To be fair, there are only two: one single blue WiFi logo hidden in the chrome strip running the modem’s waist, the other a multicolored light integrated into the power button. The former lights solid when WiFi is on, then flashes when users are connected. As for the latter, that cycles through various hues to indicate GPRS/EDGE, EDGE/WCDMA or HSPA connections (green, blue or violet respectively) together with flashing red to show low battery and amber to show charge status (flashing when charging, solid when full). There’s no obvious way to see more granular battery status; that requires accessing the MiFi’s status page.

One of the main differences between this HSPA MiFi and the CDMA versions available in the US is its microSD slot, according to the documentation happy with up to 16GB cards. With this, it’s possible to turn the MiFi into a miniature, portable NAS of sorts; access can be set as read-only or read/write, though there’s no granular password control over different users as you’d find on a full-scale NAS. From talking with Novatel, it seems this might be addressed in a future update. Access, though, is limited to anybody with encrypted WiFi access, which is likely enough control for most users, making the MiFi ideal for storing commonly-accessed files and documentation. It’s also ideal for use with a netbook, UMPC or MID, which might sacrifice internal storage for portability. A few 16GB microSD cards are a whole lot cheaper than paying for an SSD upgrade on such a device, plus they’re then of benefit to any WiFi-connected computer.

11 File Sharing_sg

So far it’s a pretty basic NAS, though. You can upload files (one at a time), open or delete them from the web interface, but there’s no way to transfer files already on the card between folders. We were also unable to map the microSD card as a network drive. On the up side, each folder can be given separate read-only or read/write status.

It’s also possible to use the MiFi as a standard, USB modem, with the supplied cable and the drivers available to install from the device itself. Novatel’s connection manager offers the usual connect and disconnect choices, with basic stats, plus an SMS app and address book. Unfortunately using a direct connection kicks the MiFi 2352 into non-WiFi mode, something Novatel’s quick start guide seems to imply is intentional but that we’d prefer was a user option. There’s no provision for topping up the MiFi’s battery via USB while also sharing its 3G connection, though of course most OSes will let you broadcast the connection over the notebook’s own WiFi.

MiFi 2352 WiFi indicator 480x373

Also new to this particular MiFi model is its processing capabilities. Novatel have given the 2352 a separate 900MHz ARM app processor, RAM and flash storage, with the obvious expectation being that there’ll be a growing catalog of third-party and homegrown mobility software that can run on the device itself. As with any new platform, however, the limitation is primarily a shortage of cooperating developers. There’s seemingly just one third-party app on offer right now, an enterprise-level device manager from Alcatel-Lucent (which we didn’t have access to for testing), while Novatel themselves have apparently developed a “basic” VPN client. With no MiFi App Store or equivalent, however, distribution seems left to carriers or hardware providers, not individual users, and there’s currently no publicly available SDK.

That’s unlikely to stop the intrepid from delving into the MiFi 2352’s Linux roots, albeit on a small scale. Having been told that the intelligent hotspot “doesn’t support Android at present, but runs an OS selected for its potential for Android installation at some point in the future” we’re feeling cautiously optimistic that – likely as the Google OS itself develops, and becomes more suited to non-smartphone devices – future MiFi units could end up with an Android Market injection.

All early days, though, and right now the bigger question is how those extra components might impact on battery life. Novatel quote the same 4hrs use/40hrs standby for the 2352 as the Sprint and Verizon MiFi 2200 units, which lack the app processor, and supply a bigger, 1,530mAh battery than the 1,150mAh in its simpler cousins. In our testing the 2352 managed a little over Novatel’s active usage estimates, complete with some standby downtime; your experience will vary on how strong the 3G signal is, and we did notice the MiFi became quite warm after extended use, particularly when it was struggling to keep a grip on a connection indoors.

MiFi 2352 unboxing slashgear 7 480x312

Officially, the MiFi 2352 is only available through one European carrier at present, Telefonica in Spain. It’s unclear if they’ve made use of the MiFi’s A-GPS abilities; there doesn’t appear to be any obvious way to access it in our non-carrier unit. Sprint’s 2200 MiFi can be set to integrate location data with such things as Google searches, automatically bringing back nearby listings ahead of more general ones. That appears to be a carrier-specific function.

Speaking of carriers, Novatel have a GSM version of the MiFi intended for US 3G bands. The MiFi 2372 is yet to show up on the company’s own webpages, but its been spotted clearing the FCC complete with support for the 850/1900MHz bands; that suggests we may be seeing an AT&T version sometime in the near future.

There’s little not to like about the Novatel Wireless MiFi 2352. It’s slightly thicker than the EVDO versions, and that’s partly because of the discrete app processor that, right now, we’re not seeing much use of, but future implementations could righten that balance. Similarly, the microSD functionality may not be as flexible as a traditional NAS, but it’s a nice bonus and a quick way to share information between devices or users.

None of that distracts from what the MiFi does best, though: sharing a single connection in a straightforward way. With a reasonable HSPA link it’s possible to fool yourself into thinking you’re at home or the office, as devices automatically hook up to the MiFi 2352’s connection and leave you to focus on what it actually was you wanted the internet for. We’re not sure on UK pricing for the 2352 (nor US pricing for the 2372) but importer Mobilx.hu are offering it, unlocked, for €220 including tax ($315/£186) and in Spain Telefonica are charging €29 or €59 per month. Considering you can realistically replace a smartphone data package, and multiple traditional USB or PC Card modem contracts, for just one MiFi connection, road warriors and traveling families could do a lot worse than checking out the 2352. Its certainly found a permanent place in our kit bag.

3G-Router 3 MiFi Huawei E5830 (Huawei i-Mo)


E5830 Huawei, Modem nirkabel yang bisa mengirimkan sinyal Wi-Fi untuk mendapatkan koneksi internet kapan pun Anda membutuhkannya. Dengan E5830, anda bisa mendapatkan kecepatan internet yang cepat tanpa kabel, tidak repot dan tidak perlu menggunakan Wi-Fi hotspot.E5830 sangat mudah digunakan dan cocok dibawa dalam saku Anda. Hanya menyalakan modem nirkabel Anda, aktifkan koneksi ke jaringan, lalu pilih fungsi Wi-Fi. Kemudian pilih opsi Wi-Fi pada perangkat manapun yang Anda gunakan. Tidak perlu untuk me-load software untuk bisa online menggunakan Huawei E5830 (Menggunakan Protokol WiFi standard). Modem wireless memberikan kecepatan download hingga HSUPA (High Speed Upload Packet Access) Downlink 7,2 Mbps dan Uplink 5.76Mbps (megabit per detik) dan dilengkapi dengan baterai yang memungkinkan Anda tetap terhubung ke internet hingga 5 jam.The E5830 juga dilengkapi dengan perangkat lunak yang dimulai setiap kali Anda menghubungkan ke PC atau laptop dengan menggunakan kabel USB. Perangkat lunak ini memungkinkan Anda untuk mengirim dan menerima pesan teks dan mengubah pengaturan untuk koneksi Wi-Fi.E5830 device , Battery, Li 1500mAh , Charger (Std. 3-pin UK) , USB cable (mini plug,standard plug) , Keep sake card with predefined SSID and Network key , No internal memory. Memory card supported Up Tp microSD 32GB , Dimensions: 86 x 46.5 x 10.5mm , Weight: 90g.
MiFi = Router yg kecil dan ada baterai (Mobile), bisa dibawa kemana2, mobil, Cafe, berbagi Internet hingga 5 user. Sangat kecil seperti sebuah Handphone. Produk paling baru dari Huawei.


Di Telkomsel dikenal sebagai FLASH BOND. Brand-New condition.




Spesifikasi:

Modem E-5830 Disebut tercanggih karena bukan saja modem ini berkemampuan 3G/HSDPA (High Speed Downlink Packet Access) dan HSUPA (High Speed Uplink Packet Access), lebih hebat lagi inilah modem pertama yang dihadirkan dengan kemampuan built in WiFi di dalamnya.


Spesifikasi Huawei E-5830 WiFi Modem

Dimensi : 95,5 x 48,6 x 13,7 mm
Berat : 90 gram (termasuk baterai)
Frekuensi : EDGE/GPRS/GSM 850/900/1800/1900 Mhz
HSDPA/3G 2100 Mhz
WiFi b/g
Downlink speed : sampai 7.2 Mbps
Uplink speed : sampai 5.76 Mbps
Eksternal Interface : USB Interface Mini USB
Standard Micro USB card
SIM/USIM card 6 pin interface
Baterai : Lithium Ion 1500 mAh 3.7 Volt
Waktu Operasi : Sampai 4 jam
Waktu Siaga : Sampai 100 jam
Power Supply : AC 100 Volt 240 Volt
DC 5.3 Volt 650 mAh
Memori Internal : 128 MB Flash, 64 MB Memory
Antena : Built in
Sistem Operasi : Windows XP/Vista dan Mac OS
Resolusi Display : > 800 x 600 pixels

Harga Rp 2.400.000,-
Garansi 3 Bulan


* Combines Circuit switched telephony service, Wi-Fi and Ethernet gateway in one device
* Instant wireless broadband access for multiple users
* No software installation needed
* Works on HSDPA,UMTS,EDGE,GPRS and GSM networks
* High speed: up to 7.2 Mbps




About GlobeSurfer® II 7.2 (Model: GS 0201)

GlobeSurfer® II 7.2 Wireless voice / data gateway is a complete, top-performance Fixed Mobile Convergence device, offering up to 7.2 Mbps wireless data connectivity on public HSDPA networks, combined with support for legacy telephone services.

GlobeSurfer® II 7.2 offers Internet access to any Wi-Fi equipped PC, without need for a fixed line public network connection. No need either for any additional software installation on the PC. Because it uses the mobile public network for Internet connectivity, GlobeSurfer® II 7.2 is ideal for workgroups working in temporary locations.

It is also the easiest to use solution to complement or replace a fixed line access at home. The completely wireless configuration enables free placement inside the house, thereby optimizing radio reception, even in difficult environments.

Moreover, GlobeSurfer® II 7.2 offers traditional circuit-switched telephony service by simply plugging any plain telephone set to its analog RJ11 connector.
GlobeSurfer® II 7.2 sleek and elegant design, and intuitive user interface, including an easy to read, informative display and its web based control panel, ensure wide acceptance in private and professional environments.

Features

* Wi-Fi certified combined Wi-Fi and Ethernet gateway
* Works with your existing fixed line telephone at home or in the office
* High speed with HSDPA and UMTS data (up to 7.2 Mbps downlink and 384 Kbps uplink) and backward compatible with EDGE/GPRS/GSM data connectivity (up to 247 Kbps)
* Global connectivity with triple-band HSDPA / UMTS (850/1900/2100 Mhz) and quad-band EDGE/GPRS/GSM (850/900/1800/1900 Mhz)
* Always gets the best out of the network, even at the borders of coverage, due to its Advanced Receiver Technology, incorporating Receiver Diversity and Equalisation
* Visual feedback of connection status on the display and the web based user interface
* Compatible with nearly all modern desktop and laptop PC�s equipped with Microsoft OS
(2000, XP, XP Pro and Vista) and MAC OS X

It is a portable and high speed internet access mode for office and home. Zero-CDROM and Multi freqbands are convenient for use remarkably. Specification

* Technical Standard
o HSDPA: 3GPP R5, up to 3.6 Mbps DL and 384 Kbps UL,category 5/6
o UMTS: up to 384 Kbps DL and UL
o EDGE: 3GPP Release4, class 12, up to 237 Kbps DL and 118Kbps UL
o GPRS: GPRS Multislot class 10, up to 85,6 Kbps DL and 42,8 Kbps UL
* Frequency Band
o GSM/GPRS/EDGE: 850/900/1800/1900 MHz
o UMTS: 2100 MHz
* Power Class
o WCDMA: Power Class 3
o GPRS 850/900: Power Class 4
o EDGE 850/900/1800/1900: Power Class E2
* External Interface
o UMTS/GSM Antenna: Internal Antenna
o USB Type: Standard USB Interface
o USB Speed: USB 2.0 High Speed
o Power Mode: Powered via the USB interface
o SIM/USIM Card: standard 6 PIN SIM card interface, compaliant with 3GPP 31.101 and 31.102


o AT Interface: 3GPP TS 27.005/3GPP TS27.007 supported
* Main Features
o Form Factor: USB STICK
o Available Colors: TBD
o Dimension (mm): 80(D)×24(W)×10(H) mm (approximate)
o Weight (g): TBD
o Visual Indicator(LED): an RGB LED indicator for different state.
o Languages Supported: English,more languages could be supported upon requested
o Zero-CD installation: Supported
o Operate System Supported: Win2000/ XP/VISTA 32bit/64bit
Mac OS X 10.4.9 or higher (only support INTEL platform)
* Main Software Functions
o Setup Mode: Plug & Auto Installation
o PIN1: Supported,enable/disable/modify
o SMS: Supported
o PhoneBook: Supported
o APN auto management: Supported
o Complete Session Statistics: Supported
o Field Test Data: Supported
o SMS and Data service simultaneously Operation: Supported
* Phonebook
o vCard version: 2.1/3.0
o new contacts: Supported
o edit contacts: Supported
o delete contacts: Supported
o send SMS: Supported
o move between SIM card and PC: Supported
* SMS
o Group messages: Supported
o new SMS: Supported
o send SMS: Supported
o save SMS to drafts: Supported
o reply SMS: Supported
o forward SMS: Supported
o delete SMS: Supported
o import from SIM to PC: Supported
* Additional Features
o Micro-SD Card Slot: Supported, Max up to 4G Supported
* Certification
o CE: Supported
o ROHS: Supported
o Microsoft WHQL: Supported
o Other: Supported
* Standard Package Contents
o HSDPA USB MODEM: 1
o Quick Start Guide: 1
* Attention
o Book, Mac Book Pro, iMac, Mac Pro or Mac mini (Intel CPU)
o Mac OS X 10.4.9 or higher
o Connect to Internet only.

Specification

* Chip Set: Qualcomm MSM6025
* Baseband: MSM6025
* Band: CDMA800MHz
* CDMA2000 1x Capability class: 153.6Kbps
* Interface Type: USB1.1
* Supply Voltage: 4.0~5.2V
* Current Consumption
o Sleep / Idle: 20~30mA
o Average In Use: 300mA
o Max.(Peak): 620mA
* Antenna: external
* Incept sensitivity: < -104dBm
* Work temperature: -20oC - +60oC
* Storage temprature: -30oC - +80oC
* Temp/Humidity test: 40oC / 93%
* Memory
o NOR SIZE: 32Mbit
o PSRAM SIZE: 8Mbit
* ME
o Size: 62 x 38 x 14(mm)
o Weight: 40g
o Cover shell material: plastic
o Antenna: External
o Indicator: Yes
* Socket & connector
o Connector type: USB 1.1
o Earphone socket: Yes
o Antenna socket: Yes
o External test RF socket: Yes
o UIM card socket: Yes
* Call
o Speech call: Yes
o Emergency call: Yes
o DTMF: Yes
o Data call: Yes
* Phonebook
o Storage No.: 1000(PC) + 100 + UIM
o Fast search: English
o Copy: UIM card to PC /PC to UIM card
o Select storage location: UIM card or PC
o Own No.: Support
* SMS
o SMS Number: 500(PC) + UIM
o Long message(SMS concatenation): Support
o Storage location selection: PC
* Network function
o Call forward: Yes
o Call limit: Yes
o Call waiting: Yes
* New feature
o Support PC OS: Windows®2000, Windows®XP, Windows®Vista
* Accessory
o RF antenna: Yes
o Earphone: Yes
o PC software

iTegno 3800

The iTegno 3800 GPRS Modem is specially designed for corporate and industrial usage. Supporting GSM/GPRS networks, iTegno 3800 offers wireless data connectivity to mobile professionals and can be deployed in various Machine-to-Machine (M2M) applications. The iTegno 38XX modem is compatible with Windows 98 SE/ 2000/ ME/ XP and Vista Operating Systems. Drivers for Linux and Macintosh OS are also available for development purposes.

General Features:
• Small size : 94.2 x 66.0 x 14.5 mm Weight: 58 grams
• Quad-band (GSM850 / EGSM900 / DCS1800 / PCS1900)
• Stable and high data transmission speeds of up to 85.6 kbps
• Available in different interfaces to suit different applications

Types of iTegno 3800 GPRS Modem Available:

iTegno 3000

iTegno 3000 is an ideal companion for mobile professionals with its light weight, portable size, embedded antenna and low power consumption.
Powered by USB, iTegno 3000 does not require batteries or battery charging. User can truly enjoy the wireless access to internet and making voice calls, sending and receiving e-mails, faxes and SMS anywhere, anytime.
iTegno is compatible with all laptops and PCs installed with Win 98SE / 2000 / ME / XP. Drivers for Linux and Mac Os are available for development purposes.

Specifications:
• Size : 93mm x 64mm x 12mm
• Weight : 58g
• Data Port: USB 1.1
• Power : USB Bus powered
• Antenna : Embedded
• GPRS Class 10: Coding scheme CS1 to CS 4
• Max. packet-switched (GPRS) data transmission speed: 85.6 kbps
• Max. circuit-switched (GSM CSD) data transmission speed: 14.4kbps
• Automatic fax group (Class 1 and Class 2)
• Cellular Service: ETSI GSM Phase 2+; Dual band auto switching (EGSM 900 / DCS 1800)
• System requirements: Windows-compatible notebook / PC; minimum 15MB free hard disk space

iTegno 3232E / 3232I

iTegno 3232E and 3232I are Class 10 RS-232 modems widely adopted by corporate and industrial users.

These two models, distinguished by different antenna types used, can be deployed in various applications including automotive systems, metering & monitoring, vending & retail, fleet & freight management and security & surveillance etc.

Specifications:
• Size : 93mm x 64mm x 12mm
• Weight : 58g
• GPRS Class 10: Coding scheme CS1 to CS 4
• Data port : 9-pin RS-232 via 1.5m cable
• Antenna:
• 3232E - external type; 50 ohm MMCX port
• 3232I - embedded type
• Power supply: 5V ~ 32V input at 500mA
• Output power:
• Class 4 (2W at EGSM 900)
• Class 1 (1W at DCS 1800)
• Power consumption: typ. average at 3Rx 2Tx
• EGSM 900@PCL 8:
• Communication - 370mA
• Idle - 31mA
• DCS 1800 @PCL 3:
• Communication - 310mA
• Idle - 31mA
• Fax service: Class 1 and Class 2
• Internet service: TCP/IP connection to PPP server via a PC host
• Software interface: AT Command (ETSI GSM 07.07 and GSM 07.05)

Merlin XU870 3G 7.2 ExpressCard - HSDPA Networks

Merlin XU870 3G 7.2 ExpressCard - HSDPA NetworksThe Merlin XU870 ExpressCard is a smaller and faster version of the traditional PC card. With global technology, the tri-band HSDPA/UMTS and quad-band EDGE/GPRS technology allows for mobile broadband connections up to 7.2 Mbps with software upgrade.
Continuing its innovation and leadership position, Novatel Wireless incorporated its wireless technology into the industry's first mobile broadband ExpressCard/34 for HSDPA networks. As added value, the product offers form factor flexibility by fitting both ExpressCard/34 and ExpressCard/54 slots.
The Merlin XU870 HSDPA 7.2 ExpressCard offers the flexibility of both HSDPA and UMTS in triband 2100/1900/850 MHz and in quad-band EDGE/GPRS 850/900/1800/1900 MHz capability. Merlin XU870 ExpressCard provides highspeed connectivity to HSDPA networks with data speeds up to 3.6 Mbps and ultimately 7.2 Mbps, with a software upgrade. It has an integrated antenna system design that incorporates an external flip antenna, maximizing data speed performance and allows for stronger network signal reception.
Best In Class * Easy to Use * Broadband Wireless Access
Key Features

* Wireless data at speeds up to 3.6 Mbps on HSDPA networks and 7.2 Mbps, with software upgrade
* Supports HSDPA, UMTS, EDGE, and GPRS
* Backwards compatible to UMTS (WCDMA) 850/1900/2100 MHz, 850/900/1800/1900 MHz EDGE/GPRS networks
* 2 Antennas
- Flip-up
- Built-in 5 bands
* Supports Windows 2000, XP, Vista; Mac; Linux
* External Antenna Connector
* Offers the latest in I/O interconnect technology
* Service State LED – 5 color
* Field firmware upgradeable

Key Benefits

* More compact than traditional PC cards
* Advanced power management
* Plug-and-play and hot swappable, without requiring a reboot
* Secure internet access
* Dependable, reliable product

BandLuxe C270 Series

Shine on Desire with Broadband Anywhere
*HSDPA 7.2Mbps & HSUPA 2Mbps
*Compact Size & Sleek Design
*MicroSD memory Card Slot (up to 8GB)
*Retractable USB Connector
*Auto APN Matching for Global Roaming
*CD-Free Auto Installation
*GSM Band: 850, 900, 1800, 1900MHz
*OS Support: Microsoft Windows vista, XP SP2+, 2000 SP4+, Mac OSX, Linux 2.6.27 and above, Win CE (by request)

C270- UMTS Band: 2100 MHz
C277- UMTS Band: 850 + 1900 MHz
C278- UMTS Band: 850 + 2100 MHz
C279- UMTS Band: 900 + 2100 MHz

BandLuxe C170 Series

Get Broadband Anywhere
*HSDPA up to 3.6Mbps
*Compact Size & Sleek Design
*microSD memory Card Slot (up to 8GB)
*Retractable USB Connector
*Auto APN Matching for Global Roaming
*GSM Ban: 850, 900, 1800, 1900MHz
*OS Support: Microsoft Windows vista, XP SP2+, 2000 SP4+, Mac OSX, Linux 2.6.27 and above, Win CE (by request)
*CD-Free Installation
C170- UMTS Band: 2100 MHz
C177- UMTS Band: 850 + 1900 MHz
C178- UMTS Band: 850 + 2100 MHz
C179- UMTS Band: 900 + 2100 MHz

The Globesurfer X.1 is a compact and bijouxgateway router device that allows anyone with a USB Modem stick to easily andreliably connect to the internet.

Packed with new and unique features, the GlobeSurfer III pushes the boundaries of conventional gateway routers. Using a Qualcomm 7225 chipset, this clever device offers HSUPA at 5.76Mbps and HSDPA at 7.2Mbps, as well as AWS support – making it a forerunner in the bandwidth market.

It also provides full telephone functionality, including composing, reading and managing SMS text messages. Hard drives and printers can be connected via the integrated USB port, enabling users to share or back-up files across the LAN, while a printer can be conveniently located and used by all connected PCs.

The GlobeSurfer III is easy to use too, with just two buttons and a clear, color display screen, while unique Notifier software displays alerts and status information across the wireless network

Hardware specifications

Powering and Interfacing

Approvals and certifications

Available accessories

Software

Voice features

Router Dual Mode bisa GSM BISA CDMA bisa disesuaikan dengan modem yang akan digunakan.

* Mobile WAN: 1x USB 2.0 port and 1x PCMCIA type II slot
* Wired WAN/LAN: 10/100Mbps, auto MDI/MDIX RJ45 port
* Wireless LAN: 1.8dBi di-pole antenna

Wireless Support

* Standard: IEEE 802.11b/g
* Security: 64-bit/128-bit WEP Encryption; WPA/WPA2 Encryption

Functionality

* Wired WAN: Static IP/Dynamic IP/PPPoE
* Wireless WAN: EV-DO, HSDPA, HSUPA, UMTS, EDGE, GPRS, CDMA1x
* NAT: One-to-Many (Max 253 users) Virtual Server, DMZ Host
* VPN Pass Through: PPTP/L2TP/IPSec
* Access Control: MAC filter, SPI firewall
* Config Management: Web-based UI./SNMP/UPnP

Environment & Certification

* Certification: FCC, CE, RoHS Compliant
* Package: Dimension : 535 x 397 x 420mm
* Weight: 0.78 Kg
* Power Supply: 5V/3A switching adapter
* Working Environment:
o Temperature: 5-50oC
o Humidity: 5%-95% non-condensing

KLIK Gambar di bawah ini untuk melihat daftar modem apa aja yang kompatible dengan router diatas..

* Qualcomm Chipset: MSM6246
* HSDPA/UMTS Bands: 2100 MHz
* EDGE/GPRS/GSM Bands: 1900/1800/900/850 MHz
* Data Speeds
o HSDPA up to 3.6 Mbps DL and up to 384 Kbps UL(*)
o UMTS up to 384 Kbps DL and up to 384 Kbps UL(*)
o EDGE up to 237 Kbps DL and up to 118 Kbps UL(*)
o GPRS up to 85.6 Kbps DL and up to 42.5 Kbps UL(*)
* Additional Support: Phonebook and SMS (group SMS)
* Mechanical
o USB Host Port: USB 2.0 Slot
o Size: (D) 85 mm x (W) 23.3 mm x (H) 13.3 mm
o Weight: about 28 gr
* Accessories Included
o Quick User's Guide and Warranty Card
o USB Cable
* Operating System Support
o Windows Vista/XP/2000
o MacOS Tiger/Leopard
* System Requirements for Laptops/PC
o USB Slots: USB 2.0 Slot
o Communication Ports: Available
o I/O Resources: IRQ, 32 bytes I/O space
o Memory: 256 MB
o Disk Space: 100 MB
* External Storage Slot: microSD up to 4 GB
* Antenna: Internal Antenna
* Power Consumption: 5V
* Operation Temperature: -10 oC to +55 oC
* Network Protocol Support: TCP/IP, PPP, and VPN
* Plug and Play Installation: Zero-CD Installation
* Certified License: Microsoft WHQL certified

(*) Depending on the GSM operator network

* Qualcomm Chipset: MSM6246
* HSDPA/UMTS Bands: 2100 MHz
* EDGE/GPRS/GSM Bands: 1900/1800/900/850 MHz
* Data Speeds
o HSDPA up to 3.6 Mbps DL and up to 384 Kbps UL(*)
o UMTS up to 384 Kbps DL and up to 384 Kbps UL(*)
o EDGE up to 237 Kbps DL and up to 118 Kbps UL(*)
o GPRS up to 85.6 Kbps DL and up to 42.5 Kbps UL(*)
* Additional Support: Phonebook and SMS (group SMS)
* Mechanical
o USB Host Port: USB 2.0 Slot
o Size: (D) 73 mm x (W) 30.8 mm x (H) 12.5 mm
o Weight: about 36 gr
* Accessories Included
o Quick User's Guide and Warranty Card
o USB Cable
* Operating System Support
o Windows Vista/XP/2000
o MacOS Tiger/Leopard
* System Requirements for Laptops/PC
o USB Slots: USB 2.0 Slot
o Communication Ports: Available
o I/O Resources: IRQ, 32 bytes I/O space
o Memory: 256 MB
o Disk Space: 100 MB
* External Storage Slot: microSD up to 8 GB
* Antenna: Internal Antenna (dual diversity)
* Power Consumption: 5V
* Operation Temperature: -10 oC to +55 oC
* Network Protocol Support: TCP/IP, PPP, and VPN
* Plug and Play Installation: Zero-CD Installation
* Certified License: Microsoft WHQL certified

(*) Depending on the GSM operator network

850/1900/2100 MHz

Power Class 3 (+24dBm).
Supports UL and DL compressed modes.
HSDPA 7.2: categories 1-4, 11 and 12.
HSDPA 3.6: categories 5 and 6.
HSDPA 7.2: category 7 and 8 (SW upgrade).
Rx diversity. Equalization
UMTS: 384 kbps operation in downlink and uplink.
CSD: 64.0, 14.4 and 9.6 kbps.


EDGE 850/900/1800/1900 MHz

GSM Power Class 4 (2W) for 850/900 bands.
GSM Power Class 1 (1W) for 1800/1900 bands.
EDGE class E2 (+27 dBm in 850/900 bands, +26 dBm in 1800/1900 bands).
GPRS/EGPRS Multislot Class 12 (4 slots Rx, 4 slots Tx).
GPRS/EGPRS Class B Type 1 MT.
GPRS CS1-CS4; EGPRS MCS1-MCS9.
CSD: 14.4 and 9.6 kbps.

Quad Band EDGE class 12 modem

Competitive speed for attractive price

Maintain your top mobility easy accessing to the Internet no matter you are in a train, bus, or in a car

Be advanced by staying online wherever you are

* Manage your business in real-time!
* Send and receive e-mails!
* Browse WEB database!
* Access VPN!
* Send SMS messages from your PC!
* Use Voice feature!

Teltonika ModemUSB/E12 connects to the PC through USB 2.0 (Universal Serial Bus) interface, which is very speedy and convenient. The modem takes the DC power directly from the USB interface, so no charging device or external AC/DC adapter is required.

We are working with the most advanced and suitable wireless bearers nowadays and looking forward to use them for our future products as far as they are reliable and suitable for customer needs. You will achieve much higher perfomance with Teltonika ModemUSB/E12 than with ordinary dial-up modem.



Main features:

The data type and data transfer speed depends on the service provided by your GSM operator. ModemUSB/E12 supports the following data-bearers:

EDGE

* 850/900/1800/1900 MHz.
* Class ES2 (26/27 dBm) for 8-PSK modulation
* Class 12
o MS class B
o Coding scheme 1-9

GPRS

* 850/900/1800/1900 MHz.
* Capacity class 4 (2W) 850/900 MHz waves
* Capacity class 1 (1W) 1800/1900 MHz waves.
* GPRS class 10.

CSD

* Data transfer speed up to 9.6 kbps



Supported Operating Systems: Windows XP (SP2); Windows Vista (supported build from version 6.0.6000); Linux with kernel 2.4.32 or higher

Drivers available: Mac OS X.

Features on demand:

* External antenna.
* Support of more than one SIM card

Great experience of branding (fully adopt the device, package and software with your brand: choose your colors, logos and brand name).
